IMET SIRIO 370

General

VERSATILE MATERIAL COMPATIBILITY

The SIRIO 370 platform is designed to expand across various material types with high precision.

• Dovetail Structural Rigidity: Like the 315, the 370 utilizes a dovetail vertical structure to ensure high cutting precision and accuracy while reducing vibrations.
• SH-E Electro-Pneumatic Control: The semiautomatic model uses hydraulic control for cutting management, allowing the operator to set all main machine parameters via a dedicated panel.
• ESC Speed Variator: Optional electronic inverter expands the blade speed from 15/30 rpm up to 15/70 rpm (or higher), allowing for the cutting of INOX steels and light alloys.

Features

• Wide Cutting Capacity: Standard vertical descent capable of processing rectangular profiles up to 7.08 in x 3.93 in (180 x 100 mm).
• Adjustable Stops: Features quick-setting stops at 0° and 45° with a graduated scale for all other angles.
• Rapid Front Vice: Equipped with transversal movement for quick material positioning and locking.
• Pneumatic Vice (SH-E): Includes a standard pneumatic front vice for automated clamping cycles.
• High-Power Motor: The manual version features a 2.0/2.9 HP (1.5/2.2 kW) motor, while the SH-E is equipped with a 4.0 HP (3 kW) motor.

Technical Data

• Max Round Cutting Capacity (0°): 4.72 in (120 mm)
• Max Square Cutting Capacity (0°): 3.93 in (100 mm)
• Max Rectangular Cutting Capacity (0°): 7.08 in x 3.93 in (180 x 100 mm)
• Miter Capacity (60° Left): Round: 4.33 in (110 mm) / Square: 3.54 in (90 mm)
• Solid Material Capacity: 1.57 in (40 mm)
• Blade Dimensions: 14.5 in (370 mm)
• Blade Speed: Standard 15/30 rpm (Optional 30/60 rpm or 15/70 rpm with ESC)
• Blade Motor Power: Manual: 2.0/2.9 HP (1.5/2.2 kW) / SH-E: 4.0 HP (3 kW)
• Working Table Height: 36.41 in (925 mm)
• Machine Weight: Manual: 859 lbs (390 kg) / SH-E: 976 lbs (443 kg)
• Dimensions: Manual: 31.8 x 40.1 x 72.8 in (810 x 1020 x 1850 mm) / SH-E: 31.8 x 42.5 x 82.6 in (810 x 1080 x 2100 mm)

Standard Equipment

• Bimetal circular saw blade (370 mm).
• Transversal movement front vice.
• Adjustable length bar stop and graduated scale.
• Pneumatic vice (SH-E version).
• Integrated coolant system.

Optionals

• Speed Variator (ESC): Inverter for 15-70 rpm (expandable to 30-140 rpm with double speed device).
• Minimal Lubrication System: Air-oil micro-mist system with a 0.34 gal (1.3 L) tank.
• Pneumatic Vice (Manual Only): Synchronized opening/closing with head movement.
• V-Jaws: Cast iron jaws for bundles and round bars up to 3.34 in (85 mm).
• Vertical Pneumatic Vice: Suitable for semiautomatic SH-E or manual units with pneumatic vice.
• Foot Pedal (SH-E Only): Remote control pedal with cable and plug.
