In stock
Dimension: 13’11’’ x 5’7 3/8’’ x 6’5’’ or 4242 mm x 1712 mm x 1956 mm
Machining precision: +/- 0.2 mm
Ability to machine at 0°, +90°, and -90°, with the possibility to machine between -90° and +90° using manual adjustment
Designed for machining aluminum and PVC
Work area dimension with a 40mm long tool:
At 0° = 2600 x 180 x 14
At +90° = 2600 x 180 x 90
At -90° = 2600 x 180 x 90
Magazine for 4 tools plus a tool for drilling
Uses ISO30 tool holders
Equipped with 4 manually positioned pneumatic clamps
Comes with a barcode reader
Programming via pre-programmed macro, custom macro, or ISO language programming
Maximum RPM: 12,000
